BD Plastipak™ Pro-Tec II 95WNiFe Tungsten Alloy Syringe Shield 3CC / 5CC

Pro-Tec II lead-free tungsten syringe shield is precision-machined exclusively for BD Plastipak™ 3 cc & 5 cc three-piece Luer-Lok syringes. Constructed from 95WNiFe tungsten heavy alloy (18.1±0.15 g/cm³). It reduces hand and finger extremity dose for technologists when handling ¹⁸F-FDG and Ga-68 in PET radiopharmacy labs. Fitted with removable black TPU shell to protect leaded glass viewing window. Material certificates including EN10204 3.1 and COA are available upon request. OEM & custom modification supported.

Product Overview

Pro-Tec II tungsten syringe shield is a lead-free radiation-protection device built for nuclear pharmacy and PET hot-lab workflows. It minimizes extremity radiation exposure during radiopharmaceutical dose drawing, manual dispensing, handheld transport and injection administration.

The shielding body is sintered and CNC-machined from high-performance 95WNiFe tungsten heavy alloy. The complete unit consists of tungsten alloy body, side leadedglass viewing window, knurled thumb-screw locking knob and split removable black TPU protective shell.

The split-style black TPU shell wraps the tungsten substrate. It absorbs impact and prevents scratches on fragile leaded glass, while offering non-slip comfortable grip for handheld operation. The TPU surface is easy to wipe and compatible with standard medical disinfection protocols.

Operators can directly read syringe graduations and observe realtime liquid volume through the leadedglass side window, without taking the syringe out of the shield. The tool-free knurled thumb-screw firmly clamps the syringe barrel to avoid accidental slippage during handling and transfer.

This high-density tungsten alloy delivers reliable attenuation for 511 keV gamma radiation from positronemitting isotopes such as ¹⁸F-FDG and Ga-68. Custom options include non-magnetic tungsten alloy, modified inner cavity dimension, resized viewing window and laser marking / OEM adjustments.

Key Features

· Exact fit for BD Plastipak™ 3cc & 5cc Luer-Lok 3-piece syringes CNC-machined internal cavity matches original syringe outer contour. Thumb-screw locking mechanism secures syringe stably.

· 95WNiFe Tungsten Heavy Alloy Core Material: 95WNiFe (95 % Tungsten, 3.5 % Nickel, 1.5 % Iron) Density: 18.1±0.15 g/cm³ Excellent gamma-ray shielding performance. More compact and lighter than equivalent lead shielding. Lead-free, non-toxic, corrosion-resistant and easy for radioactive decontamination.

· Removable Black TPU Protective Shell Protects leaded glass window from impact and scratching. Non-slip handheld grip; easy-to-clean surface for routine lab disinfection. Split-shell design enables fast syringe loading and removal.

· Side LeadedGlass Viewing Window Clear visual access to syringe scale and liquid level. No need to extract the syringe for volume verification.

· Fullset Quality Documentation & Custom Service Supply COA, EN10204 3.1 inspection certificates. Manufactured under ISO 9001 quality management. Custom machining and laser engraving are acceptable.

Applications

PET & PET CT Nuclear Medicine Departments Radiopharmacy

Hot Labs for ¹⁸F-FDG, Ga-68 dose preparation & transport Nuclear pharmacy small-volume radiopharmaceutical compounding and dose calibration

Reduction of hand/finger extremity radiation for technologists and radiochemists

Medical radiation laboratories for radiotracer sample preparation and short-term storage

 Hand-held on-site shielding during radiopharmaceutical injection

Technical Specifications

Why Zhuzhou Jiuding Metal Technology?

We are a specialized manufacturer of tungsten alloy radiation shielding components, located in Zhuzhou — China’s tungsten capital. Our inhouse workflow covers tungsten powder formulation, liquid phase sintering, precision CNC machining and finished part inspection.

Our product portfolio includes tungsten syringe shields, FDG transport pots, tungsten vial shields and custom tungsten machined parts serving nuclearmedicine customers worldwide. Both small trial orders and volume production are supported. We provide complete material documentation for hospital tender and procurement projects.

Frequently Asked Questions

Q: Which syringe does this shield fit?

A: It is purposebuilt for BD Plastipak™ 3 cc and 5 cc three piece Luer Lok syringes.

Q: What alloy and density is used?

A: 95WNiFe tungsten heavy  alloy, density 18.1±0.15 g/cm³.

Q: Can you provide material certificates?

A: Yes, COA and EN10204 3.1 inspection certificates are available upon request.

Q: Can we request custom engraving or modified dimensions?

A: OEM service is available, including laser marking and custom dimension machining.
